Description
Kaelus IPA1800A
Portable PIM analyzer for accurate passive intermodulation measurement in wireless infrastructure deployment and maintenance
| Brand | Kaelus |
| Model | IPA1800A |
| Voltage | 100-240V AC, 50/60Hz with rechargeable Li-Ion battery |
| Country of Origin | Australia |
| Weight | 7.5 kg |
| Dimensions | 350 x 280 x 120 mm |
| Warranty | 24 months |
| Certifications | CE, FCC, RoHS, IEC 60950-1 |
| SKU / MPN | IPA1800A |
| What’s in the box | IPA1800A analyzer, AC adapter, calibration certificate, RF test cables, rugged carrying case, user manual, quick start guide |
| Frequency Range | 700 MHz to 1800 MHz |
| Measurement Type | Passive Intermodulation (PIM) |
| PIM Sensitivity | -125 dBm typical |
| Output Power | 2 x 20W (43 dBm) |
| Display | 8-inch color touchscreen |
| Connectivity | USB, Ethernet, Wi-Fi, GPS |
Key benefits: High PIM sensitivity, rugged portable design, long battery life, intuitive touchscreen interface, comprehensive reporting, GPS-tagged results
Typical applications: Cellular tower commissioning, antenna system verification, DAS installation testing, RF component qualification, base station maintenance, 4G/5G network rollout
Lifecycle: Active product, current generation with ongoing firmware updates and 7+ year availability
