Description
Teledyne CCR-38S480-TD
High-performance SPDT RF coaxial switch designed for precision signal routing in demanding microwave and millimeter-wave test environments up to 38 GHz.
| Brand | Teledyne |
| Model | CCR-38S480-TD |
| Voltage | 28V DC |
| Country of Origin | USA |
| Weight | 0.15 kg |
| Dimensions | 64.5 x 64.5 x 50.8 mm |
| Warranty | 6 months |
| Certifications | RoHS, CE, MIL-STD-202 |
| SKU / MPN | CCR-38S480-TD |
| What’s in the box | RF Switch unit, datasheet, mounting hardware |
| Frequency Range | DC to 38 GHz |
| Configuration | SPDT (Single Pole Double Throw) |
| Connector Type | SMA (2.92mm compatible) |
| Insertion Loss | <0.5 dB typical up to 18 GHz |
| Isolation | >70 dB at 18 GHz |
| Switching Speed | <25 ms |
Key benefits: Wide frequency range up to 38 GHz, low insertion loss, high isolation, fast switching speed, compact rugged design, reliable latching operation, long operational life cycle.
Typical applications: Telecom test systems, ATE (Automatic Test Equipment), radar systems, satellite communication, electronic warfare testbeds, RF lab instrumentation, signal monitoring, military and aerospace test setups.
Lifecycle: Active production, long-term availability with Teledyne support
