Description
Allen-Bradley 1398-PDM-020
High-precision position feedback module designed to expand Allen-Bradley 1398 servo drive systems with accurate encoder decoding for closed-loop motion control.
| Brand | Allen-Bradley |
| Model | 1398-PDM-020 |
| Voltage | 5V DC (encoder supply), powered via 1398 drive bus |
| Country of Origin | United States |
| Weight | 0.45 kg |
| Dimensions | 120 x 75 x 40 mm |
| Warranty | 12 months |
| Certifications | CE, UL, CSA |
| SKU / MPN | 1398-PDM-020 |
| What’s in the box | 1398-PDM-020 Position Decoder Module, installation guide, mounting hardware |
| Product Type | Position Decoder Module (PDM) |
| Compatibility | Allen-Bradley 1398 ULTRA Servo Drive series |
| Encoder Inputs | Quadrature / incremental encoder interface |
| Input Signal | Differential line driver (5V) |
| Operating Temperature | 0 to 60 °C |
| Mounting | Panel / drive-integrated |
Key benefits: Seamless integration with 1398 ULTRA drives, high-resolution position feedback, noise-immune differential inputs, compact form factor, reliable industrial-grade construction
Typical applications: CNC machinery, packaging lines, printing equipment, material handling, robotics, indexing tables, textile machinery
Lifecycle: Mature/discontinued product, available as new surplus stock with limited remaining inventory
